ZSE Diesel Marine

Part Number: zse2500

Single Stage
Centrifugal Single Suction Impeller
Engine Mounted

Mechanical Seal
SAE #1 Housing
SAE 14″ Flywheel
Mega transmission
6″ weld discharge
8″ weld flange suction

ZSE 2500

2500 gpm (9463 L/M) @ 150 psi (10.3 bar)
2500 gpm (9463 L/M) @ 165 psi (11.3 bar)
1750 gpm (6624 L/M) @ 200 psi (13.8 bar)
1250 gpm (4732 L/M) @ 250 psi (17.2 bar)

Using 1 – 8″ or 3 – 6″ suction hose Rated at 2500 gpm for NFPA 1901 fire pump application ZSE 3000

3000 gpm (11,356 L/M) @ 150 psi (10.3 bar)
1500 gpm (5678 L/M) @ 250 psi (17.2 bar)

Using 2 – 8″ or 4 – 6″ suction hose Rated at 3000 gpm for NFPA 1901 fire pump application

24″L x 27″W x 31″H 605 lbs. (274 kg)

Applications

Industrial
Chemical
Aerial
ARFF
Fire Boat
